605*255(mm)Trench Grate,Black Asphaltic Coated
Product Model：
XH GG30035
C250 Grates 605mm*255mm clear opening with 38mm depth
FEATURES:
- Manufactured to BS EN 124 class C250
- Ductile iron to ISO 1083 for improved weight to strength ratio
- Black coated finish
- Customized logo and text
Applications | Estate Roads, Delivery Areas, Car Parks |
|---|---|
Accreditation | BS EN124-2:2015 |
Loading | C250 |
Grate Style | Bar, Flat |
Material | Ductile Iron |
Coating | black anticorrosive asphalt paint |
External Dimensions | 605mm x 255mm |
|---|---|
Grate Thickness | 38mm |
You need to log in to display our CAD file downloads.
