Φ450(mm)Round Manhole Cover,Key Holes,Black Asphaltic Coated
Product Model：
XH RC20003
B125 circular/round manhole cover 450mm diameter clear opening with 30mm frame depth
FEATURES:
- Manufactured to BS EN 124 class B 125
- BSI Kitemarked for third party assurance of quality
- Full single seal gives airtight seal when filled with grease
- Ductile iron to ISO 1083 for improved weight to strength ratio
- Integral Lifting key Holes
- Black coated finish
OPTIONS:
- Standard Locking
- High Security Locking
- Badging e.g. FW, SW
- Safety Grids
- Moly Sealing Grease
|
Applications
|
Driveway, Pavement
|
|---|---|
|
Accreditation
|
BS EN124-2:2015
|
|
Loading
|
B125
|
|
Cover Style
|
Solid Top
|
|
Material
|
Ductile Iron
|
|
Coating
|
black anticorrosive asphalt paint
|
|
External Dimensions
|
Φ550mm
|
|---|---|
|
Clear Opening
|
Φ450mm
|
|
Frame Depth
|
30mm
|
|
Weight:
|
17Kg
|
