600mm Rectangular Manhole cover
Product Model：
XH SR05582
D400 manhole cover 600/ 700/800mm clear opening with 80/100/100mm frame depth
FEATURES:
- Manufactured to BS EN 124 class D400
- BSI Kitemarked for third party assurance of quality
- Suitable for slow moving traffic
- Full single seal gives airtight seal when filled with grease
- Ductile iron to ISO 1083 for improved weight to strength ratio
- Black coated finish
OPTIONS:
- Standard Locking
- High Security Locking
- Badging e.g. FW, SW
- Safety Grids
- Moly Sealing Grease
Applications | Estate Roads, Delivery Areas, Car Parks |
|---|---|
Accreditation | BS EN124-2:2015 |
Loading | D400 |
Cover | Solid Top |
Material | Ductile Iron |
Frame Surface Protection By | black anticorrosive asphalt paint. |
Internal Dimensions | 600mm/700mm/800mm |
|---|---|
External Dimensions | 720mm/880mm/980mm |
Clear Opening | 600mm/700mm/800mm |
Weight: | 85Kg/106Kg/130Kg |
